Supercharger and intake manifold assembly with boost gauge on a…

A belt-driven centrifugal-style supercharger assembly mounted on a cast aluminum intake manifold sitting on a workbench, with a black drive snout, ribbed serpentine pulley, bracket plate and an Autometer boost gauge perched on top. An idler pulley, spacer block and a spare serpentine pulley lie on the bench beside it.

AI caption September 2009 · Photo 6 of 256
