Wheel speed sensor bolted to axle knuckle with bracket, Torx bol…
Tight underside detail of a wheel-speed sensor mounted to a cast steering knuckle or axle housing with a bare machined bracket, secured by a Torx-head bolt and a plated hex bolt. A gray convoluted wiring conduit runs to the black sensor connector, with the axle seal and dirt-caked castings surrounding it; an "OFF-ROAD" watermark sits in the lower right.
