Close-up into a cylinder head intake port showing the valve back…

Close-up of a bare cylinder head standing on end, shot straight down the round intake port with the back of the intake valve visible inside the runner. Installed valve springs with retainers and keepers line the deck side at left, and the machined intake flange face shows a bolt hole above the port.

AI caption January 2011 · Photo 5388 of 8450
