Automatic transmission front pump housing with splined stator sh…

Close-up of an automatic transmission front pump housing removed from the case, showing the cast-aluminum body with machined fluid passages, bolt holes and a splined stator support shaft protruding toward the camera. Traces of red transmission fluid remain in the channels and the part rests on a rag on the bench.

AI caption March 2011 · Photo 651 of 681
