Automatic transmission with pan removed on bench showing valve b…

Automatic transmission sitting upside-down on a steel workbench with the pan removed, exposing the cast fluid passages of the case, the manual valve/shift shaft with detent lever, and the filter mount. A cast-iron tailshaft/transfer case housing, output shaft and hand tools lie beside it against a red brick shop wall.

AI caption March 2011 · Photo 655 of 681
