Outboard powerhead with flywheel removed showing stator plate an…
9.8hp Merc outboardView all 3
Top of an outboard motor powerhead with the flywheel off, showing the aluminum stator plate ring, three black ignition coils on their mounts, and the tapered crankshaft stub with the timer base beneath. Green and orange harness wires, a brass fuel fitting, and the throttle linkage arm run along the lower edge, with plywood shop walls behind.
