Since some folks ask how much fluid comes out of the E4OD pan, I took a picture when I swapped in a punisher valve body.

I installed a drain plug when I last changed the trans filter. I located it on the side of the pan in the center of the magnet. This left a small amount of fluid in the bottom of the pan, but still much easier to deal with vs. not having the drain.

I was surprised how much fluid was sitting on top of the valve body. Leaving the pan under the trans during the swap let me catch most of it.
Over all I lost about half a quart.

Owner caption May 2012 · Photo 22 of 26
