What are the body mount thicknesses for the Torino/Montego/Ranchero underbody?

Per the callout boxes: Body Mount #1 is 2" W x .925", #1b is 2" W x .880", #3 is 2" W x 1.00", and mounts #4, #5, and #6 are each 2" W x .900".

Can Chevelle body mounts be used on a Ranchero according to this document?

Yes. The annotation says to use 1968–1972 Chevelle body mounts and turn them down to the thickness indicated for each body mount position. Two kits are required to have enough for a Ranchero, with some left over.

How many body mount positions are shown on the diagram?

The diagram labels an "F" body mount plus positions #1, #1b, #2, #3, #4, #5, and #6 along the underbody.

What vehicles does this underbody dimension figure cover?

Figure 18 is titled "Torino and Montego Station Wagon and Ranchero Underbody Dimensions," and the page header reads "Torino And Montego" (section 47-06-13).

Are the body mount dimensions in the callouts final?

No. The note states "These numbers are preliminary and subject to change!!!"

Home/ Registry/ Ford/ Ranchero/ 1972-1976/ “Gentleman's Truck”/ Photo supermotors.net/registry/media/1170894

Ford Torino, Montego & Ranchero Underbody Body Mount Dimensions Diagram

Torino and Montego station wagon/Ranchero underbody dimension drawing with body mount notes

‹ ›

Dimensioned underbody engineering drawing (Fig. 18) for Torino, Montego and Ranchero showing frame measurements and body-mount specifications.

AI caption May 2023 · Photo 299 of 304

This document is a scanned page (47-06-13) from a Ford shop manual showing Figure 18, "Torino and Montego Station Wagon and Ranchero Underbody Dimensions." The blueprint-style side-view diagram depicts the underbody/frame with numbered body mount positions (#1, #1b, #2 through #6, plus an "F" body mount) located along a horizontal station grid running from -50 to 140. Various vertical and horizontal dimensions (e.g., 1.25, 3.82, 4.94, 8.22, 6.33, 9.18, 7.18, 7.00, 1.70, 3.10) locate the mounts relative to the frame centerline. An uploader has annotated the scan with red callout boxes listing the size of each body mount: #1 is 2" W x .925", #1b is 2" W x .880", #3 is 2" W x 1.00", and #4, #5, and #6 are each 2" W x .900". A highlighted note advises using 1968–1972 Chevelle body mounts, turned down to the thickness specified for each mount position, and states that two kits are required to have enough mounts for a Ranchero (with some left over). The note warns that the numbers are preliminary and subject to change. The drawing carries reference number N1361-D.
