trim-panel.jpg The trim panel can be removed after the access panel if the glass is rolled up out of the way.  No other disassembly is needed.  On '78-86, remove the 4 black phillips screws from the corners of the trim panel on its rear (outer) face.  On '87-91, remove the 2 gold stamped nuts (9mm) from each inner side of the tailgate.  On '92-96, remove the 2 closed nuts (11mm) from each inner side of the tailgate.  On all, remove the 2 gold stamped nuts (9mm) inside the tailgate on each side of the regulator.  Later panels have foam rubber around the outer edge that may adhere to the paint.
trim-panel.jpg | Hits: 8280 | Posted on: 11/29/04 | View original size (240.04 KB)

The trim panel can be removed after the access panel if the glass is rolled up out of the way. No other disassembly is needed. On '78-86, remove the 4 black phillips screws from the corners of the trim panel on its rear (outer) face. On '87-91, remove the 2 gold stamped nuts (9mm) from each inner side of the tailgate. On '92-96, remove the 2 closed nuts (11mm) from each inner side of the tailgate. On all, remove the 2 gold stamped nuts (9mm) inside the tailgate on each side of the regulator. Later panels have foam rubber around the outer edge that may adhere to the paint.
