Engine bottom end with oil pan off, showing crankshaft counterwe…

Close-up looking up into the bottom end of an engine with the oil pan removed, showing oil-coated crankshaft counterweights, main bearing caps and their bolts, plus a connecting rod cap. The pan rail and gasket surface run across the bottom of the frame.

AI caption May 2005 · Photo 27 of 429
