Ford Mustang II Fuse Box Diagram – Fuse Panel Layout & Circuit Functions

This is a scanned page (34-30-2, "Fuses and Circuit Breakers") from a Ford shop manual covering fuse panel layouts and circuit assignments. The top half shows the fuse panel for full-size Ford and Mercury vehicles, illustrated with numbered callouts (1-11), the accessory feed wire, ignition key warning buzzer, and hazard warning flasher; the panel is noted as located left of the steering column on the dash panel. Its legend lists circuits protected by each fuse or circuit breaker, including warning lights, radio, windshield washer/wiper, power windows, station wagon tailgate window, heater/A-C, back-up lights, courtesy lights, hazard flasher/stop lights, and cigar lighter (amp ratings on the far left are cut off by the scan). The bottom half shows the Mustang II fuse panel diagram with the turn signal flasher and hazard warning flasher locations, followed by a 12-position legend giving amperage and circuits: e.g., #1 (4 amp) cluster/illumination lamps, #4 (6 amp circuit breaker) wiper motor, #8 (20 amp) horn and cigar lighter, #9 (15 amp) dome/courtesy circuits, #11 heater (15 amp) or A/C (35 amp) motor feed, and #12 (15 amp) back-up and turn signal lamps. A reader can identify each fuse position, its rating, and the circuits it protects on a Mustang II.
