VOLTAGE MEASUREMENTS Connect the negative lead of the voltmet…
VOLTAGE MEASUREMENTS
Connect the negative lead of the voltmeter to circuit 57 (ground) of the Stand Alone Amplifier 6 way connector, or to Pin 40 or 60 of the EEC-IV connector (EEC power ground). Measure the DC or AC voltage on the following circuits with the positive lead of the voltmeter.
