V8 engine with intake manifold removed exposing rocker arms and…

Top-down view into an engine bay with the carburetor, intake manifold and valve covers stripped off a V8, dated 11/16/2006, exposing both cylinder-head valvetrains with rocker arms and pushrods and the oily lifter valley. Spark plug wires, a yellow-sleeved line and hoses are draped across the cowl, with the air cleaner housing set aside at left.

AI caption November 2007 · Photo 544 of 948
