Tight close-up under a vehicle showing a driveshaft slip yoke, its polished chrome slip stub sliding into a red polyurethane-look seal at the mouth of a white-painted transmission tail housing. The blue-painted driveshaft tube and rear of the tailshaft are visible at left, with rust staining on the housing flange and a gray corrugated wire loom running down the right side.

AI caption June 2008 · Photo 332 of 500
