Weld bead joining a fabricated truss to an axle housing center s…

Tight shot of a fabricated truss welded over an axle housing center section, with a long stack-bead weld running from the pumpkin out along the tube and heat discoloration across the bare steel. A tab bracket is welded to the tube at upper left and a splined shaft rests behind on the bench.

AI caption July 2009 · Photo 1720 of 2723
