Disassembled chain-drive transfer case parts laid out on a garag…

A chain-drive transfer case fully disassembled and laid out on a garage floor, showing the split aluminum case halves, oil-stained cast housing, drive chain, planetary/gear sets, shift fork housing and output shafts. A 20 oz Mountain Dew bottle sits among the parts for scale, with a can of paint, a jug of paint thinner and a yellow engine stand in the background.

AI caption October 2009 · Photo 45 of 165
