Throttle shaft blade aligned with slotted TPS receiver, red arro…
Throttle Position SensorView all 43
Close-up of a throttle body showing the flat-blade throttle shaft end (top) and the matching slotted receiver of a black plastic throttle position sensor (bottom), with two red arrows indicating how the shaft blade aligns into the TPS slot. The metal casting is bare aluminum with an orange O-ring seal, resting on a white towel.
