Wiring diagram for 1990 Ford Thunderbird power mirror system.
This is a wiring diagram for the power mirror system of a 1990 Ford Thunderbird. It details the connections between the primary junction block, the left and right mirror selector switch, and the power mirrors themselves, including the up/down and left/right motors.
