chimes.jpg Buzzer & Chime Modules

The large black one in the lower L is a true [url=http://www.revbase.com/BBBMotor/Wd/DownloadPdf?id=43859]chime module[/url] used in '90-96 trucks.  The smaller black one above it is a buzzer, and they're interchangeable even though they perform differently.

[url=http://www.supermotors.net/registry/media/1092884][img]http://www.supermotors.net/getfile/1092884/thumbnail/chimecircuit.jpg[/img][/url]

The top center white one is probably from my '83 Custom.  The others are older.  Note the lack of the small terminal on the top L white buzzer.  The top R black one might be from an import.
chimes.jpg | Hits: 3619 | Posted on: 8/11/05 | View original size (732.18 KB)

Buzzer & Chime Modules

The large black one in the lower L is a true chime module used in '90-96 trucks. The smaller black one above it is a buzzer, and they're interchangeable even though they perform differently.



The top center white one is probably from my '83 Custom. The others are older. Note the lack of the small terminal on the top L white buzzer. The top R black one might be from an import.
