1986 Ford Bronco “Eddie Bauer”

“Eddie Bauer”1986 Ford Bronco

documented by Sixlitre 1,163 photos documented since 11 years documented 1 sound ♡ Follow this build

The story

Purchased new on Vancouver Island, British Columbia. Driven back and forth over the Rockies to Alberta regularly. Sold to his Brother who drove between Ottawa and Massachusetts commuting for two years. I bought in in 98 and shipped it to Baffin Island in the Canadian Arctic where I used it for two years. Shipped it back down to Ontario in 2000 where I re did the body.

Major panels replaced, new;
-Tailgate
-Door shells
-Fenders
-Rear quarters
-Hood.
-Last generation(92-96) black paddle style mirrors.
-Antenna delete cowl under windshield
-Rad support replacement underway.
-Massive 23 X 12 X 12 underhood toolbox
-Steelhorse overhead shelf
-Voltmeter and transmission gauges mounted in A-pillar pod.
-Mechanical oil pressure gauges
-Pioneer MP3/CD player,
-2 huge 4 channel amplifiers
-controlled by 80s style crossover
-4 tweeters surround overhead
-Two 6 1/2 inch midrange spkrs in doors
-Two 8 inch round midrange spkrs in rear seat area, under ashtrays
-One 10 inch woofer in cargo wall.
-Numerous anti-theft devices.
-Majorly bright headlights thanks to 12 ga. wiring, 3 relays and 14.75 volts direct to Sylvania ExtraVisions.
-Restored inner door panels
-LED front signal lights.
-Later style brighter dome light.
-Extensive additional interior lighting
-Deepened cupholders
-Extensive sound deadners and insulation
-Under floor storage compartment
-Tailgate tent · Sixlitre

Day one vs. today

Drag to compare 2004 against 2011.

1986 Ford Bronco in 2011
1986 Ford Bronco in 2004
2004 2011

Photo history

1,163 photos across 12 years. Drag the dot to travel through this vehicle’s life. Captions are the owner’s; where there isn’t one, the AI caption fills in.

2004

623 photos added · showing 8

1986 Ford Bronco: Underhood toolbox, just move washer bottle to front, shift jack handle 1986 Ford Bronco: Sets up in seconds using expanding roller poles as frame 1986 Ford Bronco: Look a little like a header ? 1986 Ford Bronco: Real direct off pass manifold eh ? 1986 Ford Bronco: Keepin' it legal 3" cat w/header flanges 1986 Ford Bronco: Can you see air pump pipe ? 1986 Ford Bronco: Talk about clearance to spare ! Thank you WD-40 for the idea 1986 Ford Bronco: Things have changed since we necked down into this stock muffler and tailpipe. More to follow

225 photos added · showing 8

1986 Ford Bronco: Here's the stock 86 oil pressure sender unit in the stock location. 1986 Ford Bronco: I removed the stock pressure sending unit and the extension pipe/log so I could clean the threads, add some s… 1986 Ford Bronco: This is the plan, once I stick a 90 degree union on the extension pipe to get me out from the block. 1986 Ford Bronco: The 90 went on with no troubles, all covered in Permatex Ultra Copper high heat gasket sealant. 1986 Ford Bronco: Screwing the T fitting to the 90 went just as well. 1986 Ford Bronco: Hooking up the plastic tubing was a walk in the park too. 1986 Ford Bronco: It's just a compression fitting, same behind the gauge inside too. 1986 Ford Bronco: The only tough part is deciding where to run the tubing through the firewall. I chose to crowd this grommet,…

37 photos added · showing 8

1986 Ford Bronco: This is what 7 year old velvet ride shackles on 7 year old 3/4 ton springs looks like. Holding up alright in… 1986 Ford Bronco: Red Dodge Charger R/T concept car on a show lawn with display placard, three-quarter front view 1986 Ford Bronco: Here's the little LED light inside the leather key fob from Radio Shack. Had it for a year and it's super bri… 1986 Ford Bronco: On the same chain is the tiny little one inch blade that's gonna cut through the seat belt, as I'm upside dow… 1986 Ford Bronco: Rear of orange Dodge Challenger concept with full-width taillight bar at auto show 1986 Ford Bronco: Chrome CHALLENGER badge and red side marker on an orange Dodge Challenger rear quarter panel 1986 Ford Bronco: Low close-up of orange Dodge Challenger concept front end and five-spoke wheel at auto show 1986 Ford Bronco: Black leather bucket seat and silver-trimmed dash inside orange concept coupe

112 photos added · showing 8

Brass drain valve and IMPORTANT label on gray household water heater in basement Gray basement water heater tank with drain pipe into a bucket and nearby circulator pump 1986 Ford Bronco: I'd show you the old glass but it blew up and shattered. Note one of the slider rails that bolts to the glass… 1986 Ford Bronco: You can see the busted glass is still wedged in between the plastic grommets. The splayed rivets are not norm… 1986 Ford Bronco: Looking at the back of the plate you can see the rivet heads. 1986 Ford Bronco: There's a better close up 1986 Ford Bronco: And the other side of the rivet, the part splayed at the factory. 1986 Ford Bronco: The grinder makes short work of removing the non-splayed side.

45 photos added · showing 8

1986 Ford Bronco: Inside shot of the ceiling insulated and the electrical all hooked up. Note one of the 7 quad outlets. 1986 Ford Bronco: Was all set to install 6 double tube fluorescent fixtures (480 watts total). Tried the new 100 watt equivalen… 1986 Ford Bronco: R-22 Roxul insulation done, poly barrier started. 1986 Ford Bronco: If you don't weld and your part rusts out, you can always slice the pipe with a sawzall and get it off the pi… 1986 Ford Bronco: Drill out four holes to ease access for your jigsaw. The MDF is 10 1/4" square and starts out as 3/4" thick. 1986 Ford Bronco: Jigsaw the hole out a 1/4" bigger than the 8" midrange component speaker. 1986 Ford Bronco: Check the speakers have plenty of clearance in the covers holes. 1986 Ford Bronco: Set the table saw at the blade's width to shave off the majority of the covers backside material.

52 photos added · showing 8

1986 Ford Bronco: What do you do, after six years of Ontario salt damage, when your collector flange falls off when the pipe ro… 1986 Ford Bronco: Not pretty on the outside anymore, but inside the flow qualities of that Flowmaster Y are unfettered and stil… 1986 Ford Bronco: Canadian female hockey player 1986 Ford Bronco: Canadian beer fridge 1986 Ford Bronco: A pile of stuff came off the Mopar to get to the chain 1986 Ford Bronco: Wheel bearing seal puller 1986 Ford Bronco: Looking at this one Stainless steel band exhaust clamp with two mounting bolts

1 photo added

1986 Ford Bronco: Performance Unlimited exhaust tubing selection guide with horsepower chart and diameter vs. area circles

25 photos added · showing 8

1986 Ford Bronco: 2010 all grown in 1986 Ford Bronco: Fits right into the back yard 1986 Ford Bronco: Good colour I think 1986 Ford Bronco: Gotta get a light for over that door 1986 Ford Bronco: Got a dead short in the old 86' starter. Changed it at least twice since I've owned it and decided to upgrade… 1986 Ford Bronco: 65 bucks brand new from RockAuto this week, brand new. Yeah there's metric on it. The hot lead is a 14mm nut… 1986 Ford Bronco: The lower post, with the blue cable from the positive battery clamp, is alway hot. On a stock 86 the top post… 1986 Ford Bronco: Here's the 2 gauge, stock starter cable being removed from the top post in preparation for mounting it onto t…

19 photos added · showing 8

1986 Ford Bronco: New 4 hole injectors are reckoned ot to clog up as easily and the 4 holes are better on gas mileage too 1986 Ford Bronco: Same electrical connector for simple hook up to my older 86 injector harness connectors. 1986 Ford Bronco: There's the Ford part number in case you're wondering. 1986 Ford Bronco: Scored mine at the local pick & pull for $22.75 for all eight. Out of a 4.6 Mercury Grand Marquis 1986 Ford Bronco: Hand pressing an illuminated white rectangular courtesy lamp in dark blue carpeted trim 1986 Ford Bronco: Steel ruler across blue interior panel with lit rectangular dome light 1986 Ford Bronco: Lit festoon bulb in chrome dome light housing with steel ruler for scale, dark blue carpet trim. 1986 Ford Bronco: Big thanks to Brother drkhrs925, at FSB, for showing me the right way to do this.

1 photo added

1986 Ford Bronco: Don't own a torch or too afraid to heat the offending fastener ? You might well get away using this. Often ti…

5 photos added

1986 Ford Bronco: Here we are ten years on and Dalton's liquid salt has played havoc with the brake lines. Last time I saved th… 1986 Ford Bronco: Quick trip to NAPA and part # WH-7818 to the rescue. I'd have paid a lot more than 3.99 to save my @$$ on thi… 1986 Ford Bronco: Here is the adapter fitting threaded into the axle brake hose union block. Wonder if anyone makes those axle… 1986 Ford Bronco: This is the rectangular spring that DOESN'T come in you combi kit. You know the one that flies off under the… 1986 Ford Bronco: Found the little b@$turd !

18 photos added · showing 8

1986 Ford Bronco: 10 years since my last PC build. Did it again in a box with an integrel handle on the top and the all importa… 1986 Ford Bronco: Really like this Enermax ECR 301 Mighty Charger. It charges your phones etc REALLY fast even when the compute… 1986 Ford Bronco: Went with an small SSD for the operating system and a huge conventional hard drive for storage. A fanless 2GB… 1986 Ford Bronco: an eight core 4ghz AMD processor with a great Gigabyte Motherboard and 16 GBs or RAM makes this FAST 1986 Ford Bronco: 20 pin USB connector to the motherboard 1986 Ford Bronco: 10 pin USB header connector 1986 Ford Bronco: SATA and Molex power connectors 1986 Ford Bronco: Bought my last cooler in 84. It had been dead for ten years, but I finally threw it out last year. According…
