Driving Caliper Clips Out, rubber style (Ford F2TZ2C150A; MC BRCK5030)

The stainless shells of the clip have 2 catches at each end holding the clip to the steering knuckle. Use a hammer & drift to knock the outboard catches inside the groove so the clip can be pushed through.

The inner pad anti-rattle clip is D6TZ2B164C. ACDelco set of 6 clips

--------------------------------------------------------------------------------

TSB 98-5A-13 NEW SPECIFICATION - Silicone Brake Caliper Grease and Dielectric Compound to be used for Disc Brake Caliper Slides

Publication Date: MARCH 18, 1998

FORD:
1984-1994 TEMPO
1984-1996 MUSTANG, THUNDERBIRD
1985-1996 CROWN VICTORIA, ESCORT
1986-1996 TAURUS
1989-1996 PROBE
1994-1996 ASPIRE
1995-1996 CONTOUR

LINCOLN-MERCURY:
1982-1996 CONTINENTAL
1984-1994 TOPAZ
1984-1996 COUGAR
1985-1996 GRAND MARQUIS
1986-1996 SABLE, TOWN CAR
1987-1989 TRACER
1991-1994 CAPRI
1991-1996 TRACER
1993-1996 MARK VIII
1995-1996 MYSTIQUE

LIGHT TRUCK:
1983-1996 RANGER
1986-1996 AEROSTAR
1990-1996 BRONCO, ECONOLINE, F SUPER DUTY, F-150-350 SERIES
1991-1996 EXPLORER
1993-1996 VILLAGER
1995-1996 WINDSTAR
MEDIUM/HEAVY TRUCK: 1990-1991 C SERIES
1990-1996 F & B SERIES

ISSUE: The use of petroleum-based grease as a lubricant in servicing disc brakes is no longer acceptable because it may be incompatible with the rubber material used in the disc brake system. If petroleum-based grease is used to lubricate any part of the disc brake system, it could cause rubber parts to swell if lubricant contacts the rubber material.

ACTION: Refer to the following Servicing Procedures for details.

DISC BRAKE SERVICING
CAUTION: DO NOT USE PETROLEUM-BASED SERVICE GREASE (SUCH AS FORD DISC BRAKE CALIPER SLIDE GREASE D7AZ-19590-A) TO LUBRICATE DISC BRAKE CALIPER SLIDE PINS OR RUBBER DUST BOOTS. PETROLEUM-BASED GREASE MAY CAUSE EPDM RUBBER TO SWELL.

When servicing any disc brakes, lubricate necessary components by applying Silicone Brake Caliper Grease and Dielectric Compound (D7AZ-19A331-A (Motorcraft WA-10)) or an equivalent silicone compound meeting Ford Specification ESE-M1C171-A. Refer to the appropriate Service Manual for specific service details.

DRUM BRAKE SERVICING
When servicing drum brakes, apply Silicone Brake Caliper Grease and Dielectric Compound (D7AZ-19A331-A (Motorcraft WA-10)) or an equivalent silicone compound meeting Ford Specification ESE-M1C171-A to the contact points between the brake shoes and the drum backing plates for lubrication.

NOTE: DISC BRAKE CALIPER SLIDE GREASE D7AZ-19590-A SHOULD NO LONGER BE USED FOR DISC BRAKE CALIPER SLIDE LUBRICATION.

OTHER SERVICE APPLICATIONS
Existing inventory of D7AZ-19590-A may be used for all other Service Manual procedures. Once material is exhausted, all vehicle procedures specifying Disc Brake Caliper Slide Grease (D7AZ-19590-A) should use Silicone Brake Caliper Grease and Dielectric Compound (D7AZ-19A331-A).

PART NUMBER : PART NAME
D7AZ-19A331-A : Silicone Brake Caliper Grease And Dielectric Compound



OTHER APPLICABLE ARTICLES: NONE
SUPERSEDES: 95-21-02
