Ford V8 engine bay with corroded radiator side tank, fan shroud…

‹ ›

Radiator removal 4nov03View all 10

Close-up of steel line and hex tube nut threaded into a corroded brass fitting

Open radiator filler neck with scaling next to transmission cooler line and engine pulleys

Copper hard line and brass fitting on a bracket beside a radiator core in an engine bay

Chrome Craftsman wrench on hex bolt at black radiator support with vacuum decal below

Brass line fitting circled in red marker on rusty bracket near radiator support

Person in white hoodie resting on a beige living room couch with throw pillows

Close-up of engine pulleys and belts, with a rusty water pump housing

Radiator top neck with brass fitting and metal line, next to black fan shroud

Engine bay with blue valve covers and visible belts and pulleys

10photos in this albumView all

Engine bay of a Ford V8 with the grille and core support opened up, showing a radiator with a heavily corroded side tank and hose neck, a black fan shroud, and the crank pulley and fan hub. Blue spark plug wires, a chrome-topped air cleaner, foil-wrapped hose and a blue-painted engine block fill the right side.

AI caption November 2003 · Photo 44 of 112
