Ford wiring schematic diagram for rear axle speed sensor, EBAS,…

Ford wiring schematic diagram for rear axle speed sensor, EBAS, PSOM and speed control modules
Ford wiring schematic diagram for rear axle speed sensor, EBAS, PSOM and speed control modulesOriginal file
Ford wiring schematic diagram for rear axle speed sensor, EBAS, PSOM and speed control modules

PSOM for '96 pickups. '92-95 similar.
http://www.revbase.com/BBBMotor/Wd



CHECK SPEED INPUT SIGNAL

NOTE: Only wiring harness end of connector is to be probed.
* Connect Rotunda Digital Volt-Ohmmeter 014-00407 or equivalent to Pin 4 (speed in ) and Pin 5 (speed in -).
* Does the voltage increase smoothly and continuously from 0 to approximately 3.5 volts as vehicle speed increases from 0 to 48 km/h (0 to 30 mph)?
OR:
* If available, a frequency counter may be connected to Pin 4 (Speed in ) and Pin 5 (Speed in -).
* Does the displayed frequency of the signal increase smoothly and continuously from 0 to approximately 667 Hz at approximately 48 km/h (30 mph)?
OR:
* If neither a voltmeter nor frequency counter is available, vehicle speed control may be used as a good indicator. If it works normally, then the speedometer module is at least receiving a speed input signal and the wiring and ABS sensor (DY1123, F85Z-9E731-AB) can be assumed to be good.

Rear axle sensor should read 800-1400 Ohms across the pins, and more than 10 Ohms from the metal shell to either pin

Owner caption · Photo 628 of 6546
