LSXkilr Dyno Chart 2020 - 364.3 HP @ 6300 RPM, 348.3 lb-ft Torque Graph

This document is a scanned engine dynamometer (DYNOmite) test chart produced by LSXkilr Custom Calibrations, labeled as test "Alfred #3" run on 2020-08-05 at 14-37-47. The chart plots corrected Peak Torque and Horsepower versus engine RPM over a range of approximately 3000 to 7000 RPM, with torque/HP scales from 0 to 400. Two main curves are shown: a blue torque curve labeled "#3 Torque" with a peak callout of 348.3 lb-ft (348.3 TQ) around the mid-4000 RPM range, and a red horsepower curve labeled "#3 Hp" with a peak callout of 364.3 HP. A row of markers labeled "#3 AFR" (air/fuel ratio) runs along the bottom of the plot. A footnote states the correction method is "Standard" and confirms Peak Power: 364.3 Hp @ 6300 RPM. The notes field contains only the default placeholder text ("Type any notes about your test here"). A reader can learn the engine's measured peak torque, peak horsepower, the RPM at which peak power occurs, the shape of the power and torque curves across the RPM band, and who performed the tuning/testing (LSXkilr Custom Calibrations). The document does not identify the specific vehicle, engine displacement, or modifications.
