SOLD Amp & Harness for 94-96 premium radio & CD tested working on all 4 channels. The harness will fit '92-96 trucks, and possibly '87-91. The radio connectors on the L of the pic will only fit '94-96 Premium Sound option radios.
The connectors on the R side mate to the standard radio connectors in most '87-96 Ford vehicles.
.
See also:
MotorCraft 2016 Wiring Pigtail Guide
