Engine bay showing AC compressor, belt pulleys and wiring

Bolt everything down, put the belt & clutch connector back on, fill the reservoir with Type F (for pumps from '98-older vans), check for belt interference, and start it up. I had to tie the upper hose back slightly. This pump is silent compared to the C2.

If the pump foams, cycle the steering wheel lock-to-lock a couple of times at idle keeping the fluid level topped off in the reservoir, then shut the engine off for ~30min, and try again.



A pump from a '98-up van probably uses MerconV, but few of them have Saginaw pumps (because they have modular engines - not smallblock V8s).

Owner caption August 2011 · Photo 3652 of 6546
