MotorCraft Wiring Pigtail Catalog 2009
IF THE IMAGE IS TOO SMALL, click it.
This is sometimes available online free.

Bronco Wiring Pigtail List
(use CTRL F to search this page)
----------------------------------------------------------------------
Component (Pins & Gender) Pigtail Application
----------------------------------------------------------------------
4WD Indicator Lamp (2F) WPT-757 80-86
4WD Range Switch (2M) WPT-209/1081 87-96
ABS Sensor, Rear Differential (2M) WPT-1300 87-96, Std. S699/HP4475
A/C Compressor Clutch (2M) WPT-173 93-96 AuVeCo 232087, Std. S942/HP3855
A/C Clutch Cycling Switch, low pressure (2F) WPT-438 80-96 AuVeCo 23168
ACT Sensor (2M) WPT-428 87-95, Std. S567
Ambient Sender (2F) WPT-497 94-96, Std. S2181
Amplifier (14M) WPT-296 94-96
Battery Negative Cable (1F) WPT-??? 90-97, Std. A364UT
Battery Positive Cable (1F) WPT-??? 90-97, Std. A494TA
Blower Motor (2M) WPT-104 92-97, Std. S581
Blower Resistor (4M) WPT-114 80-97, Std. S630/HP4350
Blower switch (4M) WPT-103 92-97 AuVeCo 23051, Std. S624/HP4340
BOO Switch (2M) WPT-197 66-977, Std. S831/HP4715
Brake Shift Solenoid (3M) WPT-210 94-96, Std. S2210
CANV Solenoid (2M) WPT-441 87-95
Chime Module (7M) WPT-512 90-96
CHMSL/Cargo Lamp (2F) WPT-492 WPT-530 WPT-593/594 92-96
Cigar Lighter (1F) 80-96 WPT-476 AuVeCo 23209
Clearance Dash Harness (2F) WPT-473/474 87-97
Clearance Lamp Harness (2M) WPT- 87-97
Compressor Control Switch (4M) WPT-344 92-96
Coolant Sender (1M) WPT-476 66-96 Standard S635
Courtesy Lamp (Door) (2F) WPT-212 92-96
Courtesy Switch (3F) WPT-213 80-96 EXC.92-93, Std. S1792
Courtesy Switch (3F) WPT-1001 92-93, Std. S657
CPP Switch (6M) WPT-507 87-96, Std. S1782
Defrost Switch (5M) WPT-377 92-96
Defrost Terminal (1F) WPT-371 WPT-434 78-96
Dimmer Switch (3F) 80-91 AuVeCo 23139
Distributor/PIP (6F) 92-97 WPT-???, Std. S1756
DLC EEC-IV (6M) WPT-743 87-95
DLC OBD-II (16F) WPT-615 96, Std. S1796
Dome Lamp (1F) WPT-265 (for Bk/LB wire)
Door Courtesy Lamp (2F) WPT-356 92-96
Door Mirror (4F) 92-97 WPT-???, Std. S2194
Door Mirror Harness (8M) WPT-382 96, Std. S1879
Door Mirror Switch (8M) WPT-313 92-96
DPFE Sensor (3M) WPT-458 95 AuVeCo 23119, Std. S924
Driver Switch Panel (15M) WPT-656 92-96
DRL Module (8M) WPT-298
E-brake Switch (1M) WPT-488 WPT-748 92-96, Std. S2435
ECT Sensor (2M) WPT-437 87-95, Std. S612/HP4400
ECT Sensor (2M) WPT-433 96, Std. S2034/HP4665
Emissions Indicator Lamp (2F) WPT-757 83-86
ESOF Module (5M) WPT-300 90-96, Std. S2144
ESOF Module (8M) WPT-313 90-96
ESOF Motor (8F) WPT-174 96 ???
ESOF Motor (10M) WPT-661 90-96, Std. S1883
EVP Sensor (4M) WPT-386 87-95 AuVeCo 23119
EVR Solenoid (2M) WPT-374 87-96, Std. S1842
Fuel Injector (2M) WPT-372 85-95 3U2Z14S411ATA, Standard S2161, Std. SK25/HP3980, cheap EV1 pigtail x8
Fuel Tank Harness (4F) WPT-454 87-93
Fuel Tank (4M) WPT-171/1262 94-95
Fuel Tank Harness (4F) WPT- 94-95
Fuel Tank (4M) WPT-1008 96-04
Fuel Tank Harness (4F) WPT-152 96-04
Hood Lamp (2M) WPT-370 WPT-4951 87-96
Horn (1M) WPT-378 87-96 AuVeCo 23209, 23258, Std. S2237
Headlamp (3M) WPT-301 WPT-603 80-86
Headlamp (3M) WPT-110 87-96, Std. S525/HP3940
Headlamp Switch (9F) WPT-165 92-96 1U2Z-14S411-AAB7, Std. S607/HP3820
HEGO 21 (4M) WPT-112 96
HEGO 11/12 (4M) WPT-111 WPT-123 87-96
Hood Lamp (2M) WPT-270
HVAC Panel Lamp (2M) WPT-597 92-96, Std. S2394
IAC (2M) WPT-684 87-96, Std. S663
Ignition Coil (2M) WPT-595 78-87
Ignition Coil (3M) WPT-397 87-96, Std. S539/HP4370
Ignition Control Module (3M) WPT-601 (3F)WPT-706 78-87
Ignition Control Module (6M) WPT-297 86-96 Standard S544/HP4530
Ignition Switch (11M) 80-91 AuVeCo 23169, Std. S611
Ignition Switch (16M) WPT-577 92-96 AuVeCo 23182, Std. S713
Inertia Fuel Shutoff Switch (3M) WPT-1001 90-96 AuVeCo 23180
Instrument Cluster (14M) WPT-383 83-96
Instrument Bulb Holder (2F) 80-96 AuVeCo 23290
Knock Sensor (2M) WPT-462 87-95
License Lamp (2F) WPT-149 WPT-492 80-96 AuVeCo 23295
Lock Motor (2M) WPT-312, WPT-1117 92-96, Std. S1018
Lumbar Seat Power (2M) (2F) WPT-484 '92-96, Std. S1353
MAF Sensor (4F) WPT-256/3U2Z14S411ACA 94-95 AuVeCo 23039
MAF Sensor (6M) WPT-102 96, Std. S1094
MAP Sensor (3M) WPT-263 87-95 AuVeCo 23033, Std. S613
Map Lamp (1F) WPT-674 (for LG/Y wire)
Marker Lamp, front (2F) 87-96 AuVeCo 23295
MD (2F) 96 WPT-???, Std. S819/HP4710
MFS (7F) WPT-179 92-96 AuVeCo 23037, Std. S665
MFS (9M) WPT-611 92-96, Std. S2430/S662/HP4135
MLPS (original) (8M) WPT-389 95-96, Std. S798/S2225
MLPS (revised) (12M) WPT-??? 89-96, Std. S812
Oil Sender (1M) WPT-616 66-96 Standard S635/S2247
Park/Turn Lamp (3F) 80-91 AuVeCo 23185
Park/Turn Lamp (3F) WPT-442 92-96
PFE Sensor (3M) WPT-458 94-95 AuVeCo 23206
Power Point (2M) WPT-355 WPT-633 WPT-719 92-96 AuVeCo 23437
Power Seat (2M) (2F) WPT-484 '92-96
PSOM (12M) WPT-613 92-96
PSP Switch (2M) WPT-372 87-95
Radio (8M gray) WPT-646 87-96
Radio (8M black) WPT-696 87-96
Rear View Mirror (3M) WPT-584 94-96
Refrigerant Pressure Switch (4M) WPT-169 96
Reverse Lamp (2F) 80-90 AuVeCo 23031
Reverse Lamp (2F) WPT-291 92-96 AuVeCo 23029
RFI Capacitor (2M) WPT-478 87-96
RKE Module (13M) WPT-612, WPT-625 94-96
RKE Module (16M) WPT-632 94-96
SCDS (2F) WPT-??? 94-97
Seat Belt Switch, Left (3F) WPT-473 (3M) WPT-113 80-96
Speaker (2M) WPT-416 87-96 AuVeCo 23024
Speed Control (Cruise) Deactivator Switch (original) (2M) WPT-232 WPT-260 93-96, Std. S697/HP3860
Speed Control (Cruise) Deactivator Switch (revised) (2M) , Std. S1080
Speed Control (Cruise) Servo (10M) WPT-762 93-96, Std. S1875
Starter Cable (1F) WPT-??? 92-97, Std. A604LF
Starter Relay (1M) WPT-616 80-96 Standard S635
Starter Solenoid (1F) WPT-371 92-96
Stator (1M) WPT-851 WPT-852 WPT-1129 87-96 Pico 5747PT
TAD Solenoid (2M) WPT-146 87-95
Tailgate Window Dash Switch (5M) WPT-653 87-96
Tailgate Window Defrost Terminal (1F) WPT-371 WPT-434 78-96
TCIL/TCS (3F) WPT-229 (3M) WPT-214 92-96
Temperature Sender (1F) 80-97 WPT-???7, Std. S635/HP3830
TPS (3M flat) WPT-445 87-96 AuVeCo 23040
TPS (3F round) WPT-651 87-96
Trailer Brake Controller (3M) WPT-412 80-91
Trailer Brake Controller (4F) WPT-456 92-93
Trailer Brake Controller (6F) WPT-599 94-96, Std. TC710
Trailer Connector (3F1M) WPT-840 66-96
Trailer Connector (4F) WPT-358 66-96
Trailer Adaptor (4M) WPT-171/1262 66-96
Trailer Connector (7M) WPT-421 80-96
Trailer Adaptor USCAR (7F) WPT-975 11-up
Transmission (12F) WPT-590 89-up E4OD/4R70W
Turn Flasher (2M) WPT-710 87-89
Valve Body (12M) WPT-571 89-96
Visor (1M) WPT-562 94-96
Visor (2M) WPT-233 '96
Visor Harness (2F) WPT-226 '96
VMV (2M) WPT-545 96, Std. S1752
Voltage Regulator (4F) 80-85 AuVeCo 23140
Voltage Regulator (3M) WPT-119 87-96, Std. S545/HP3910
Washer Pump (2F) AuVeCo 23437
Window Motor (2M) (2F) WPT-484 80-96
Wiper Motor (3M) WPT-333 87-93
Wiper Motor (6M) WPT-297 94-96, Std. S918
