Ford Lightning 5.8L Headers Exploded Diagram - Exhaust Manifolds 9430/9431

This document is an exploded parts diagram titled "Lightning 5.8L Headers," showing the left-hand and right-hand exhaust manifolds (headers) for the Ford Lightning 5.8L engine. Two illustrations are provided: the upper drawing depicts the L.H. exhaust manifold assembly and the lower drawing depicts the R.H. exhaust manifold assembly, each shown removed from the cylinder head with dashed lines indicating bolt alignment. Ford base part number callouts identify the components: 9448 is the exhaust manifold gasket (called out on both sides), 9431 is the left-hand exhaust manifold, and 9430 is the right-hand exhaust manifold. The attaching hardware is identified as bolt 381732-S with hardware reference (BB-869-H), shown for both sides. The diagram illustrates how the manifolds, gaskets, and bolts assemble to the cylinder heads, with the surrounding engine components (valve covers, cylinder heads, and accessories) drawn for orientation. A reader can learn the Ford part numbering for the Lightning 5.8L header components and the general assembly relationship of the gaskets, manifolds, and mounting bolts. No torque specifications, dates, or additional notes are visible. The image carries a "Steve83" watermark.
