Vapor Valves

The smaller valve (E7DZ9B593A) uses a thicker (smaller I.D.) grommet (E3EC9B076AA or F6TZ9B076AA) to fit in the same fuel tank hole as the larger valve (E8UZ9B593A or imported copy) with a thinner grommet (E8UA9B076AA or E8UZ9B076A).

.

Owner caption · Photo 2850 of 6546
