Manual transaxle specifications screen with lubricant grade, 2.0…

Manual transaxle specifications screen with lubricant grade, 2.0L and 2.5L gear ratios and differential shim sizes
Manual transaxle specifications screen with lubricant grade, 2.0L and 2.5L gear ratios and differential shim sizesOriginal file
Manual transaxle specifications screen with lubricant grade, 2.0L and 2.5L gear ratios and differential shim sizes

Reference · 1993-1997 ProbeAll 10 manual pages
