1968-82 Chevrolet Corvette Coupe Weatherstrip Diagram - T-Top & Door Seals

This document is a line-art illustration showing the weatherstrip locations on a 1968–1982 Corvette coupe body. The drawing depicts the front three-quarter view of the coupe with the weatherstrip channels rendered in bold black lines around the roof and door openings. Four callout labels identify the weatherstrip positions: the T-Top weatherstrip along the removable roof panels, the Windshield Post weatherstrip along the A-pillar, the Door Glass Rear weatherstrip at the rear vertical edge of the door glass opening, and the Door Main weatherstrip around the main door opening perimeter. The caption in the lower-left corner reads "68-82 Coupe Weatherstrip," indicating the diagram applies to 1968 through 1982 coupe models. A reader can use this diagram to identify which weatherstrip piece is which when ordering replacement seals or diagnosing wind noise and water leaks around the T-tops and doors. No part numbers, dimensions, or installation instructions appear in the image — it is purely a location/identification reference showing where each of the four named weatherstrip sections sits on the coupe body.
