Power Window/Lock driver's connector '92-96 WITHOUT factory RKE.

Note the L-shaped hole for the index pin on the Left lock switch above position 5. The lock switch for the Right door has a U-shaped index pin. All window switches have a round pin, whose holes are visible below positions 7 & 9.

Owner caption · Photo 2721 of 6546
