column9296tiltex.jpg '92-96 Steering Column
This is a mixed-up diagram because it shows a horn pad on a '92-93 wheel, but it also shows a '94-96 clock spring for an airbag.

Non-tilt columns are identical, other than NOT having the tilt handle (13K359/3D544) installed, and having the lock mechanism (3B661/3D653) pinned.

7A214 & 7G550 [url=https://www.amazon.com/dp/B07GVLL698]Bezel & TCIL/TCS [/url]

For complete teardown, reassembly, & installation, see:

[url=https://www.supermotors.net/registry/6098/31472-4][img]https://www.supermotors.net/getfile/701936/thumbnail/steeringcolumn92up.jpg[/img][/url]
column9296tiltex.jpg | Hits: 5905 | Posted on: 11/7/11 | View original size (527.87 KB)

'92-96 Steering Column
This is a mixed-up diagram because it shows a horn pad on a '92-93 wheel, but it also shows a '94-96 clock spring for an airbag.

Non-tilt columns are identical, other than NOT having the tilt handle (13K359/3D544) installed, and having the lock mechanism (3B661/3D653) pinned.

7A214 & 7G550 Bezel & TCIL/TCS

For complete teardown, reassembly, & installation, see:
