What is the deck capacity of the Jerr-Dan 16AWL on this plate?

The deck capacity is listed as 8,000 lbs, with a note that this indicates the structural capacity of the components, not the effective transport load.

What is the towbar/wheellift capacity shown?

The towbar/wheellift capacity is 3,000 lbs (structural capacity, not effective transport load).

What chassis is this Jerr-Dan unit installed on?

The truck chassis VIN is 1GBKC34FXVJ106316 with a 114-inch C.A. (cab-to-axle) dimension, and a rear axle weight rating of 11,000 lbs on the first (drive) axle with no second (tag) axle.

What warning does the plate give about exceeding load limits?

Loss of vehicle control, which could result in serious bodily injury or death, can occur if the effective transport load is exceeded. If the equipment is installed on a different chassis, Jerr-Dan must be contacted for a revised rating.

Home/ Registry/ Ford/ Crown Victoria/ 1998-2011/ 2001 Ford Crown Victoria/ Photo supermotors.net/registry/media/985736

Jerr-Dan 16AWL Rollback Carrier Data Plate - Deck & Wheellift Capacity Specs

Jerr-Dan wrecker manufacturer data plate listing capacities and weight ratings

‹ ›

Jerr-Dan tow-body manufacturer ID/spec plate listing model, serial, deck and towbar capacities and axle weight ratings.

AI caption June 2013 · Photo 2753 of 5000

This photograph shows a riveted metal manufacturer's data/specification plate from Jerr-Dan Corporation (1080 Hykes Road, Greencastle, PA 17225; 1-800-926-9666) mounted on a rollback carrier/tow truck body. The plate identifies the unit as Model No. 16AWL, Serial No. 38336, with a deck capacity of 8,000 lbs and a towbar/wheellift capacity of 3,000 lbs, noting these figures indicate structural capacity of the components rather than effective transport load. Truck chassis information lists VIN 1GBKC34FXVJ106316 with a 114-inch cab-to-axle (C.A.) dimension. Rear axle weight rating (GAWR) is 11,000 lbs for the first (drive) axle, with no second (tag) axle (N/A). A weight table states maximum allowable loads with tag axle up: 4,850 lbs on the carrier deck with 0 lbs on the towbar/wheellift, or 2,000 lbs on the carrier deck with 1,500 lbs on the towbar/wheellift (tag-axle-down values are all N/A). Warning text explains that exceeding the effective transport load can cause loss of vehicle control, serious injury, or death, and that ratings depend on the specific chassis — Jerr-Dan must be contacted for a revised rating if the equipment is moved to another chassis. The plate is copyright 1993 by Jerr-Dan Corporation.

This document covers 1993, which may differ from this 2001 Ford Crown Victoria.

Is this accurate? Sign in to help verify it.

Frequently asked questions

What is the deck capacity of the Jerr-Dan 16AWL on this plate?: The deck capacity is listed as 8,000 lbs, with a note that this indicates the structural capacity of the components, not the effective transport load.
What is the towbar/wheellift capacity shown?: The towbar/wheellift capacity is 3,000 lbs (structural capacity, not effective transport load).
What are the maximum combined load limits listed on the plate?: With tag axle up: 4,850 lbs on the carrier deck with 0 lbs on the towbar/wheellift, or 2,000 lbs on the carrier deck with 1,500 lbs on the towbar/wheellift. Tag-axle-down values are all N/A.
What chassis is this Jerr-Dan unit installed on?: The truck chassis VIN is 1GBKC34FXVJ106316 with a 114-inch C.A. (cab-to-axle) dimension, and a rear axle weight rating of 11,000 lbs on the first (drive) axle with no second (tag) axle.
What warning does the plate give about exceeding load limits?: Loss of vehicle control, which could result in serious bodily injury or death, can occur if the effective transport load is exceeded. If the equipment is installed on a different chassis, Jerr-Dan must be contacted for a revised rating.
