1994 Ford Bronco Exhaust System Layout - Hand-Drawn Routing Sketch

Hand-drawn line routing diagram from a radiator-like unit to the rear wheels

‹ ›

Simple hand-drawn routing schematic showing fluid or brake lines running from a front unit to the rear axle wheels.

AI caption March 2007 · Photo 13 of 645

This document is a simple hand-drawn (computer-sketched) diagram, uploaded as "exhaust.jpg" to a 1994 Ford Bronco gallery on SuperMotors.net. It appears to depict an exhaust system layout in a rough, freehand style: a dark blue rectangle at the top likely represents the engine or exhaust manifold area, with several curved black lines (pipes) running down from it. Two pipes travel down the drawing; one passes through a light-blue rectangle in the middle of the layout, which contains a short, mostly illegible handwritten scrawl (possibly "cat," suggesting a catalytic converter). Two black donut/oval shapes near the bottom likely represent mufflers or exhaust outlets, with pipes continuing past them to the bottom of the image. The drawing contains virtually no legible text — no part numbers, dimensions, torque specs, or legend. A reader can only glean a general conceptual routing of a dual-pipe exhaust arrangement from the manifold(s) down through a converter to the rear, presumably for the owner's 1994 Ford Bronco, though the document itself states no year, make, model, or engine applicability.
