Ford Taurus SHO V6 DIS Wiring Diagram - Distributorless Ignition Schematic

V6 Ford Taurus SHO distributorless ignition system schematic with sensors, DIS module and coil pack
V6 Ford Taurus SHO distributorless ignition system schematic with sensors, DIS module and coil packOriginal file
V6 Ford Taurus SHO distributorless ignition system schematic with sensors, DIS module and coil pack

Reference · 1992-1995 TaurusAll 12 schematics

Ford Taurus SHO V6 DIS Wiring Diagram - Distributorless Ignition Schematic Ford DIS Module Pin-Out - 3.0L SEFI SHO & 3.8L SEFI SC Ignition Module Diagram Ford DIS Ignition Timing Diagram - PIP, CID, SPOUT & Coil Current Waveforms Ford DIS Ignition Block Diagram - EEC-IV, Coil Pack & Sensor Wiring (V6) Patent drawings Fig. 3 and Fig. 4 of dual plenum intake with interconnecting passageway V6 Engine PCV / Blow-By Gas Flow Schematic - Crankcase Ventilation Diagram Ford EEC Self-Test Diagnostic Connector Pinout - Signal Return, Fuel Pump Pins 3.0L SHO accessory drive belt routing with generator, A/C compressor and idler pulley callouts 3.2L SHO ATX drive belt routing with power steering, tensioner, generator and A/C pulleys Ford OBD-I Self-Test Hookup Diagram - DLC & STI Connector Jumper Wire (Taurus) V-type engine crankcase ventilation cross-section with fresh air and blow-by gas flow through hoses Ford EEC Self-Test Input (STI) & Data Link Connector (DLC) Diagram - Taurus 12schematics1992-1995 Ford Taurus More reference Focus Fanatic Hocus SHOcus opening spread with the SHO-powered Focus ZX3 by a dockBrochure Excess-Air Factor λ & Ignition Timing Effects on HC, NOx, CO Emissions - ManualManual page Ford Taurus 3.0L V6 Spark Plug Wire & Coil Pack Routing Diagram (1993)Wiring diagram SHO Time swap steps 10-14: shorter Fram PH3614 oil filter, A/C compressor, accessory brackets and exhaustService procedure 1987-95 Ford Taurus SHO TRW Rack & Pinion Steering Parts Diagram & Part NumbersExploded parts 1993 Ford Taurus Fuse Box Diagram - Panel Layout, Flasher & Color CodesFuse chart Aluminum H-Brace Fabrication Blueprint - 1993 Ford Taurus DIY Brace DrawingBlueprint Ford Mustang GT Coupe Premium window sticker with MSRP, fuel economy label and 5-star safety ratingsSpec plate Ford SHO 3.0L/3.2L V6 Engine Specs - Valve, Camshaft, Rod & Bearing ClearancesTorque spec

Schematic of the V6 Taurus SHO distributorless ignition system showing sensors, DIS module, coil pack and PCM.

Part of 1992-1995 Ford Taurus Schematics

AI caption · Photo 739 of 1028

This document is a wiring schematic for the Distributorless Ignition System (DIS) on the V6 Ford Taurus SHO. It shows how the Cam Position Sensor (CID signal) and Crank Position Sensor (PIP signal) connect to the DIS Module, and how the DIS Module drives a three-coil coil pack that fires the six spark plugs in waste-spark pairs: Coil 1 fires plugs 1 and 5 (Y/BK wire), Coil 2 fires plugs 3 and 4 (Y/R wire), and Coil 3 fires plugs 2 and 6 (Y/W wire). Both sensors receive VBAT power on R/LG wires and ignition ground on O/R wires. The schematic identifies DIS Module pin numbers (1, 2, 3, 4, 5, 7, 8, 9, 11, 12) and PCM pin numbers (4 for IDM, 24 for CID, 36 for Spout, 56 for PIP). Wire color codes are labeled throughout, including LB for CID, GY for PIP, DG and DB signal wires, Y/G for the Spout signal, and GY/O, T/Y, W/PK at the DIS Module IDM circuit. A reader can use this diagram to trace ignition wiring, identify sensor and module pinouts, and diagnose DIS-related no-spark or misfire problems on the SHO's 3.0L/3.2L V6 ignition system.

Is this accurate? Sign in to help verify it.

Frequently asked questions

Which spark plugs does each coil fire on the Taurus SHO DIS coil pack?
Coil 1 fires plugs 1 and 5, Coil 2 fires plugs 3 and 4, and Coil 3 fires plugs 2 and 6.
What wire colors connect the DIS module to the coil pack?
Coil 1 uses Y/BK, Coil 2 uses Y/R, and Coil 3 uses Y/W.
Which PCM pins carry the DIS signals?
PCM pin 24 is CID, pin 56 is PIP, pin 4 is IDM, and pin 36 is the Spout signal (Y/G wire).
How are the cam and crank position sensors powered?
Both sensors receive VBAT on R/LG wires and ignition ground (IGN GND) on O/R wires.
What wire colors carry the CID and PIP sensor signals?
The cam position sensor CID signal is on an LB wire and the crank position sensor PIP signal is on a GY wire.
