Cougar gauge check module wiring diagram for 1996

'96 Cougar Gauge Check Module
IF THE IMAGE IS TOO SMALL, click it.

This module is an expanded version of the Anti-Slosh Module; it also turns on the light for high temperature or low oil pressure. But it will work normally if some of the inputs are NOT connected.
