'92-96 Bronco headliner exploded diagram with numbered callouts

'92-96 Bronco Headliners
IF THE IMAGE IS TOO SMALL, click it.
Actual size: 62x55x8" 5.3 lbs

1 - Roof Trim Panel - 51944
2 - Drive Pin (1 Req'd Each Side) - 383927-S
3 - Moulding - 517C04 & 518B34
4 - Quarter Trim Panel - 31012
5 - Body Side Garnish Moulding - 29010
6 - Front Body Pillar Inside Moulding - 3598
7 - Windshield Garnish Moulding - 03606
8 - Roof Trim Panel, Rear - 519C14
9 - Rear Cargo Lamp - 13K706
10 - Rear Courtesy Lamp Lens - 13K707
11 - Cowl Side Trim Panel Retainer (2 Req'd) - 02354
12 - Coat Hook - 29024
13 - Screw - N610021-S424
