Ford 5.4L V8 Engine Exploded Parts Diagram - Intake, Injectors, Coils (A0055202)
Exploded parts diagram of an engine intake manifold with fuel rail, injectors, and throttle body.
This document is an exploded parts illustration from a Ford service reference showing the upper engine assembly components of a V8 engine (uploaded and labeled by the owner as a 5.4L engine diagram). The drawing depicts, in exploded view from top to bottom: the throttle body with gasket and mounting bolts, an idle air control/EGR-related valve assembly at upper right, an engine wiring harness at upper left, an EGR valve, the fuel supply manifold (fuel rails) with eight fuel injectors, eight coil-on-plug ignition coils, PCV/vacuum tubing, the thermostat housing with thermostat and coolant outlet, the intake manifold with mounting bolts, the intake manifold gaskets, a heater/coolant hose at right, a sensor with wiring lead, and finally the engine block (cylinder block) with cylinder heads at the bottom. Dashed alignment lines show how each component stacks onto the intake manifold and engine block. The only text visible in the document is the Ford illustration reference number "A0055202" in the lower left corner; there are no callout numbers, part numbers, torque specifications, or legend text on this page. It appears to be one page (page 5) of a multi-page engine disassembly/assembly illustration set.
Is this accurate? Sign in to help verify it.
Frequently asked questions
- What does this diagram show?
- It is an exploded parts illustration of a Ford V8 engine's upper assembly, showing the throttle body, EGR valve, fuel rails with eight injectors, eight ignition coils, thermostat housing, intake manifold and gasket, hoses, and the engine block with cylinder heads.
- Does the diagram include part numbers or torque specs?
- No. The only text visible on the illustration is the reference number A0055202 in the lower left corner; no part numbers, callout legend, or torque values appear on this page.
- How are the components arranged in the illustration?
- In exploded view order from top to bottom: throttle body and related valves/harness, EGR valve, fuel rails and injectors, ignition coils, vacuum tubing, thermostat housing, intake manifold, intake gasket, and the engine block, with dashed lines showing assembly alignment.
- What is the illustration reference number?
- A0055202, printed at the bottom left of the drawing.
