What wire colors run from the master switch to the rear window switches?

The diagram shows circuits 193 YE/LG, 317 GY/OG, and 316 YE/LB to the left rear switch, and 319 YE/BK and 320 RD/BK to the right rear switch.

What connectors are used for the rear power window switches and motors?

The left rear power window switch uses connector C701 and its motor uses C704; the right rear switch uses C801 and its motor uses C804. The master switch side shows C510 and continues to C609 on page 100-3.

How are the rear power window circuits grounded?

Both rear switches ground through circuit 57 BK via splices S774 and S864 to ground G200 (see grounds, page 10-14).

Does the wiring differ with keyless entry?

Yes. The diagram shows separate routing labeled 'W/KEYLESS ENTRY' (via splice S272) and 'W/O KEYLESS ENTRY' (via splice S263), both on circuit 193 YE/LG going to C609 on page 100-3.

Home/ Registry/ Ford/ Mustang/ 2005-2014/ “SHELBY GT500”/ Photo supermotors.net/registry/media/724094

Ford Power Windows Wiring Diagram 100-004 - Rear Window Switches & Motors

Power windows wiring diagram 100-004 with rear window switches and motors

‹ ›

Automotive wiring diagram for power windows showing left and right rear window switches, motors and color-coded circuits.

AI caption April 2009 · Photo 842 of 4867

This is page 100-004, titled 'Power Windows', from a Ford factory-style wiring diagram set. It shows the rear power window circuits: the left front (master) power window switch assembly with its lock-out switch and the left rear and right rear window switch sections (UP/DOWN), continuing to page 100-3 via connector C609 with separate routing for vehicles with and without keyless entry (splices S272 and S263 on circuit 193 YE/LG). The diagram details the left rear power window switch (connector C701) and right rear power window switch (connector C801), each with switch illumination fed by circuit 19 LB/RD from the instrument illumination circuit (page 71-3). Wire circuits shown include 193 YE/LG, 317 GY/OG, 316 YE/LB, 319 YE/BK, and 320 RD/BK between the master switch and rear switches; 884 YE/BK and 885 YE/LB to the left rear power window motor (C704); and 881 BN and 882 BN/VE to the right rear power window motor (C804). Grounding is via circuit 57 BK through splices S774 and S864 to ground G200 (see grounds page 10-14). Connector pin numbers are labeled at each switch and motor, making this useful for diagnosing rear window switch, motor, wiring, or ground faults.

Is this accurate? Sign in to help verify it.

Frequently asked questions

What wire colors run from the master switch to the rear window switches?: The diagram shows circuits 193 YE/LG, 317 GY/OG, and 316 YE/LB to the left rear switch, and 319 YE/BK and 320 RD/BK to the right rear switch.
What connectors are used for the rear power window switches and motors?: The left rear power window switch uses connector C701 and its motor uses C704; the right rear switch uses C801 and its motor uses C804. The master switch side shows C510 and continues to C609 on page 100-3.
How are the rear power window circuits grounded?: Both rear switches ground through circuit 57 BK via splices S774 and S864 to ground G200 (see grounds, page 10-14).
What powers the rear window switch illumination?: Switch illumination in both rear switches is fed by circuit 19 LB/RD from the instrument illumination circuit, shown continuing to page 71-3.
Does the wiring differ with keyless entry?: Yes. The diagram shows separate routing labeled 'W/KEYLESS ENTRY' (via splice S272) and 'W/O KEYLESS ENTRY' (via splice S263), both on circuit 193 YE/LG going to C609 on page 100-3.
