What are the door lock circuit colors?

Circuit 117 Door Lock Motor (Lock) is Pink-Black Stripe, 119 Door Lock Switch (Lock) is Pink-Yellow Stripe, 121 Door Lock Switch (Unlock) is Pink-Green Stripe, and 122 Door Lock Motor (Unlock) is Pink-Orange Stripe.

Which circuit feeds the heater blower motor and what color is it?

Circuit 181, Fuse Panel to Heater Blower Motor, is Orange.

What color is the starter motor relay to starter motor wire?

Circuit 128, Starter Motor Relay to Starter Motor, is Black; circuit 113, Starter Motor to Starter Motor Relay, is Yellow-Black Stripe.

Home/ Registry/ Ford/ Bronco/ 1978-1979/ “buyers guide”/ Photo supermotors.net/registry/media/966753

1979 Ford Bronco Wiring Color Codes - Circuits 96-207 Wire Color Chart

Standard Wire Color Code Chart, circuits 90-207, remote mirror and door lock

‹ ›

Wire color code page covering circuits 90-207: windshield wiper ground, remote control mirror, power door lock motor, 2-speed axle, glow plug and radio circuits with wire colors.

AI caption February 2013 · Photo 51 of 104

This document is one page of a Ford wiring circuit color-code reference table, listing circuit numbers 96 through 207 with each circuit's description and its corresponding wire color. It covers a wide range of vehicle electrical systems, including windshield wiper controls, charging system connections (alternator and voltage regulator), remote control mirrors, starter motor relay circuits, door lock motors and switches, glow plug circuits, two/three-speed axle shift motors, back-up lamps, speed control, air conditioning blower and thermostat circuits, heater blower, key/door buzzer warning system, emergency brake warning lamp, 3 x 6 module circuits (over ride switch, carburetor solenoid, disabler solenoid, throttle angle, third gear switch, vacuum switch, indicator lamp), headlamp switch feeds, marker lamps, and towing vehicle ground return. A reader can use this table to identify the function of a given numbered circuit in Ford wiring diagrams and to trace wires by their color and stripe pattern (e.g., circuit 150 Battery Feed to Fuse Panel is Red; circuit 137 Fuse Panel to Radio is Yellow-Black Stripe). This page is part of a multi-page wiring color-code set uploaded to accompany a 1979 Ford Bronco's wiring diagrams. The document itself shows no year, model, or part numbers.

Is this accurate? Sign in to help verify it.

Frequently asked questions

What color is circuit 150, the battery feed to the fuse panel?: Circuit 150 (Battery Feed to Fuse Panel) is Red.
What wire color runs from the fuse panel to the radio?: Circuit 137, Fuse Panel to Radio, is Yellow-Black Stripe.
What are the door lock circuit colors?: Circuit 117 Door Lock Motor (Lock) is Pink-Black Stripe, 119 Door Lock Switch (Lock) is Pink-Yellow Stripe, 121 Door Lock Switch (Unlock) is Pink-Green Stripe, and 122 Door Lock Motor (Unlock) is Pink-Orange Stripe.
Which circuit feeds the heater blower motor and what color is it?: Circuit 181, Fuse Panel to Heater Blower Motor, is Orange.
What color is the starter motor relay to starter motor wire?: Circuit 128, Starter Motor Relay to Starter Motor, is Black; circuit 113, Starter Motor to Starter Motor Relay, is Yellow-Black Stripe.
