What fuse powers the power mirror circuit in this diagram?

Fuse 17, a 20A fuse in the fuse box, supplies power via a White/Black (W/B) wire to the mirror switch.

What wire colors connect the mirror switch to the mirror motors?

Green (G), Brown (Br), and White (W) wires feed the LH mirror motor, and Green/Red (G/R), Brown/Red (Br/R), plus shared White (W) feed the RH mirror motor circuit.

What connectors are used for the left and right mirror motors?

The LH mirror motor circuit uses connectors G27/H05 (or H01/H05), H11/H12, and H10. The RH mirror motor circuit uses G28/H06 (or H04/H06), H07/H08, and H09.

What do the [1] and [2] footnote symbols mean in this diagram?

[1] indicates wiring/connectors for IWATA-built 4-door and 2-door vehicles; [2] indicates CAMI-built 4-door vehicles.

How many motors are in each side mirror?

Each mirror assembly (LH and RH) is shown with two motors, controlled by the UP/DOWN and RH/LH contacts of the mirror switch.

Home/ Registry/ Suzuki/ Samurai/ 1986-1995/ “Little Blue”/ Photo supermotors.net/registry/media/420688

Suzuki Power Mirror Wiring Diagram - Mirror Switch, Motors & 20A Fuse Circuit

Power mirror wiring diagram with mirror switch and left/right mirror motors

‹ ›

Wiring diagram of the power mirror circuit showing the mirror switch and the LH and RH mirror motors with color-coded wires.

AI caption August 2006 · Photo 56 of 86

This document is a wiring diagram for a power (electric remote-control) mirror system. Power originates at fuse 17 (20A) in the fuse box and feeds through a White/Black (W/B) wire via connectors E37/G06 and G04/H02 (or G29/H03, depending on build variant) to the mirror switch. The mirror switch contains four contact sets labeled (RH), (LH), (UP), and (DOWN), each with OFF/ON positions, plus a selector section with LH/RH/N positions. Switch outputs run through Green (G), Brown (Br), White (W), Green/Red (G/R), and Brown/Red (Br/R) wires to the left and right mirror motors. The LH mirror motor is fed through connectors G27/H05 or H01/H05, then H11/H12 and H10; the RH mirror motor is fed through G28/H06 or H04/H06, then H07/H08 and H09. Each mirror assembly contains two motors (up/down and left/right adjustment). A Black (B) ground wire runs through connector H02/G04 to two chassis ground points (9 and 10). Footnotes indicate connector variants: [1] applies to IWATA-built 4-door and 2-door vehicles, [2] applies to CAMI-built 4-door vehicles. A reader can trace fuse rating, wire colors, connector numbers, and pin assignments for diagnosing power mirror faults.

Is this accurate? Sign in to help verify it.

Frequently asked questions

What fuse powers the power mirror circuit in this diagram?: Fuse 17, a 20A fuse in the fuse box, supplies power via a White/Black (W/B) wire to the mirror switch.
What wire colors connect the mirror switch to the mirror motors?: Green (G), Brown (Br), and White (W) wires feed the LH mirror motor, and Green/Red (G/R), Brown/Red (Br/R), plus shared White (W) feed the RH mirror motor circuit.
What connectors are used for the left and right mirror motors?: The LH mirror motor circuit uses connectors G27/H05 (or H01/H05), H11/H12, and H10. The RH mirror motor circuit uses G28/H06 (or H04/H06), H07/H08, and H09.
What do the [1] and [2] footnote symbols mean in this diagram?: [1] indicates wiring/connectors for IWATA-built 4-door and 2-door vehicles; [2] indicates CAMI-built 4-door vehicles.
How many motors are in each side mirror?: Each mirror assembly (LH and RH) is shown with two motors, controlled by the UP/DOWN and RH/LH contacts of the mirror switch.
