Titan Engines Install Notes, Core Return & Warranty Info Sheet - Ocala FL
Reference · 1992-1996 BroncoAll 142 service procedures
Titan Engines instruction page covering install notes, core return, warranty info, and break-in driving instructions.
Part of 1992-1996 Ford Bronco Service Procedures
This document is an installation and warranty information sheet from Titan Engines, a remanufactured engine supplier located in Ocala, Florida. The sheet contains five sections. 'Install Notes' lists requirements to preserve the engine warranty: replacing the oil cooler on equipped vehicles, priming the oil pump and purging air from the oiling system before startup, servicing or replacing the radiator, readjusting adjustable rocker assemblies after engine run-in, and thoroughly cleaning the oil pan, valve covers, timing cover, and intake manifold without sand blasting or other media, since dirt entering the oil system may void the warranty. 'Core Return' explains how to return the old engine core: attach the supplied core tag, bag and strap the engine to the pallet, and contact the Shipping Manager to arrange freight return; Titan will assess the core for remanufacture as a long or short block. 'Warranty Information' instructs the buyer to fill out and fax the Vehicle Information sheet, after which the warranty company sends the policy in roughly two weeks. 'Contact Information' provides the address (2120 NW 10th Street, Ocala, Florida 34475), phone numbers (1-352-732-8006, 1-888-477-8006), website, and email. 'Driving Instructions' describe the location on Highway 27 near I-75 exit 354 for core drop-off.
Is this accurate? Sign in to help verify it.
Frequently asked questions
- What must be done before starting a Titan remanufactured engine?
- The oil pump must be primed and the oiling system purged of air before the engine is started. On vehicles equipped with an oil cooler, the oil cooler must be replaced or the warranty may be voided.
- How do I return my old engine core to Titan Engines?
- Attach the supplied core tag to the old engine, put the engine in the plastic shipping bag it was shipped in, strap it to the pallet, and contact Titan's Shipping Manager to arrange a freight transportation company to return the core.
- Can I sand blast the oil pan, valve covers, timing cover, or intake manifold before installation?
- No. These parts must be thoroughly cleaned, but not sand blasted or cleaned with any other media, because dirt from these items entering the oil system may void the warranty.
- How do I get my warranty policy from Titan Engines?
- Fill out the supplied Vehicle Information sheet and fax it to Titan's office. Approximately two weeks later the warranty company will send you the policy and other related materials.
- Where is Titan Engines located?
- Titan Engines is at 2120 NW 10th Street, Ocala, Florida 34475, on Highway 27 (10th Street) just two miles east of I-75 in Ocala; the I-75 exit is 354. Check in at the front counter before bringing a core to the drop-off area.
