What vehicles does the Wild Horses #792030 Saginaw/Delphi steering pump kit fit?

The kit is designed for use on 78-79 Ford Broncos and 77-79 F-150 trucks with the 351M/400M engine, with or without air conditioning.

What belt is recommended for the Wild Horses Saginaw pump kit?

A belt is not included due to pulley size variation, but the instructions state AutoZone #17540 or #6485MC (with A/C) or AutoZone #17555 (without A/C) fit most of the time.

What fluid should be used in the power steering system with this kit?

Use non-synthetic auto parts store power steering fluid. Do not use automatic transmission fluid. Fill to proper level, start the vehicle, and turn the steering right to left to bleed air, then recheck fluid levels.

What parts come in the kit?

The parts list includes a pump bracket, pump brace, pump with pulley (optional), pump adjustment link, pump spacer and bolt kit (not shown), and pressure hose, plus hardware: one 7/16NC x 6" bolt, five 7/16 flat washers, two 3/8NC x 1 1/4" bolts, one 3/8NC x 1" bolt, a 1/2" pump brace spacer, and a 9/16" pump bracket spacer for non-A/C vehicles.

How is a non-A/C installation different from an A/C installation?

For A/C vehicles no washers should be needed at the head bolt; for non-A/C vehicles use the 9/16" spacer between the head and pump bracket to align the pulleys.

Home/ Registry/ Ford/ Bronco/ 1978-1979/ “RANGER XLT”/ Photo supermotors.net/registry/media/1109736

Wild Horses Saginaw Steering Pump Kit #792030 Instructions - 78-79 Bronco 351M/400M

Wild Horses Saginaw/Delphi steering pump kit parts list and install instructions

‹ ›

Wild Horses Four Wheel Drive Saginaw/Delphi steering pump kit sheet with labeled parts and step-by-step installation instructions.

AI caption June 2017 · Photo 176 of 262

This document is an installation instruction sheet from Wild Horses Four Wheel Drive (Stockton, CA) for their Saginaw/Delphi Power Steering Pump Kit, part numbers #792030 and #792030KIT, dated 7/10/13 rev. 0. The kit is designed for 1978-79 Ford Broncos and 1977-79 F-150 trucks with 351M/400M engines, with or without air conditioning. The sheet includes a labeled photo of the kit components (pump with optional pulley, pump bracket, pump brace, brace spacer, adjustment link, pressure hose), a parts list, and a hardware list specifying bolt sizes (7/16NC x 6", 3/8NC x 1 1/4", 3/8NC x 1") and spacers (1/2" brace spacer, 9/16" non-A/C bracket spacer). Step-by-step instructions cover disconnecting the battery, removing the stock pump and brackets, mounting the pump to the bracket, attaching the bracket and brace to the engine head and water pump, differences between A/C and non-A/C installations, recommended belts (AutoZone #17540 or #6485MC with A/C, AutoZone #17555 without A/C), setting belt tension, installing the pressure hose, and filling/bleeding with non-synthetic power steering fluid (not ATF).

Is this accurate? Sign in to help verify it.

Frequently asked questions

What vehicles does the Wild Horses #792030 Saginaw/Delphi steering pump kit fit?: The kit is designed for use on 78-79 Ford Broncos and 77-79 F-150 trucks with the 351M/400M engine, with or without air conditioning.
What belt is recommended for the Wild Horses Saginaw pump kit?: A belt is not included due to pulley size variation, but the instructions state AutoZone #17540 or #6485MC (with A/C) or AutoZone #17555 (without A/C) fit most of the time.
What fluid should be used in the power steering system with this kit?: Use non-synthetic auto parts store power steering fluid. Do not use automatic transmission fluid. Fill to proper level, start the vehicle, and turn the steering right to left to bleed air, then recheck fluid levels.
What parts come in the kit?: The parts list includes a pump bracket, pump brace, pump with pulley (optional), pump adjustment link, pump spacer and bolt kit (not shown), and pressure hose, plus hardware: one 7/16NC x 6" bolt, five 7/16 flat washers, two 3/8NC x 1 1/4" bolts, one 3/8NC x 1" bolt, a 1/2" pump brace spacer, and a 9/16" pump bracket spacer for non-A/C vehicles.
How is a non-A/C installation different from an A/C installation?: For A/C vehicles no washers should be needed at the head bolt; for non-A/C vehicles use the 9/16" spacer between the head and pump bracket to align the pulleys.
