What transfer case does this diagram cover?

The Borg-Warner BW 1356 manual shift transfer case, shown in an exploded parts view and in installed positions for the Ford F-150 and Bronco.

What is the torque spec for the transfer case attaching bolts?

The installation views call out bolts torqued to 41-54 N·m (30-40 lb-ft); another bolt is labeled 20-27 N·m.

Does the Bronco use a fixed or slip yoke on the BW 1356?

The diagram is annotated 'Bronco Fixed Yoke,' with the fixed-yoke output components circled on the exploded view.

What transmissions are referenced with the BW 1356 in this document?

The shifter detent plate note references the ZFHD & ZFLD manual transmissions and the C6 automatic transmission.

Does this page include a parts legend for the numbered callouts?

No. The exploded view uses numbered callouts, but the corresponding parts list/legend is not included on this scan.

Home/ Registry/ Ford/ Bronco/ 1992-1996/ “Big '92”/ Photo supermotors.net/registry/media/261575

Ford BW 1356 Manual Shift Transfer Case Exploded Diagram - Bronco & F-150

Exploded parts drawings of BW 1356 manual-shift transfer case and transmission shifter detent plates

‹ ›

Exploded parts breakdown of a BorgWarner 1356 manual-shift transfer case with shifter detent plate views for Bronco, F-150 and F-250.

Part of 1992-1996 Ford Bronco Exploded Parts Diagrams

AI caption November 2005 · Photo 641 of 2193

This scanned page from a Ford service reference covers the Borg-Warner (BW) 1356 manual-shift transfer case. The left portion is a detailed exploded parts diagram showing the complete disassembly of the transfer case, case halves, input/output shafts, planetary gear set, drive chain, bearings, snap rings, seals, and the output yoke, identified by numbered callouts (no parts legend is included on this page). The uploader has circled the front output/yoke area and hand-labeled it 'Bronco Fixed Yoke,' highlighting the fixed-yoke rear output configuration used on the Bronco. The right portion shows installation views of the transfer case mounted to the transmission for both F-150 and Bronco applications, with labels for the transmission, vent, shifter assembly, shift rod, skid plate, gasket, U-nut, and mounting bolts, including torque specifications of 41-54 N·m (30-40 lb-ft) for attachment bolts and 20-27 N·m for another fastener. A partially legible torque specification table at the bottom lists values for case half attaching bolts, the 4WD indicator switch, and the front output gear yoke, alongside a 'Shifter Detent Plates' note for ZFHD & ZFLD manual and C6 automatic transmissions. Useful for anyone rebuilding or reinstalling a BW 1356 transfer case.

Is this accurate? Sign in to help verify it.

Frequently asked questions

What transfer case does this diagram cover?: The Borg-Warner BW 1356 manual shift transfer case, shown in an exploded parts view and in installed positions for the Ford F-150 and Bronco.
What is the torque spec for the transfer case attaching bolts?: The installation views call out bolts torqued to 41-54 N·m (30-40 lb-ft); another bolt is labeled 20-27 N·m.
Does the Bronco use a fixed or slip yoke on the BW 1356?: The diagram is annotated 'Bronco Fixed Yoke,' with the fixed-yoke output components circled on the exploded view.
What transmissions are referenced with the BW 1356 in this document?: The shifter detent plate note references the ZFHD & ZFLD manual transmissions and the C6 automatic transmission.
Does this page include a parts legend for the numbered callouts?: No. The exploded view uses numbered callouts, but the corresponding parts list/legend is not included on this scan.
