What years of Ford Bronco does this body mount diagram cover?

The diagram is labeled 'Bronco 1980-96', so it covers 1980 through 1996 Ford Broncos.

How many body mount positions are shown on the Bronco frame?

The diagram shows the Radiator Core Support mount plus four numbered body mount positions: Position #1, Position #2, Position #3, and Position #4.

Which callout numbers correspond to each mount position?

Radiator Core Support uses items 1-8, Position #1 uses items 9-13, Position #2 uses items 14-18, Position #3 uses items 19-24, and Position #4 uses items 25-29.

Does this diagram include part numbers or torque specs for the body mounts?

No. It only shows numbered callouts for the hardware stacks at each mount position; no part numbers, torque values, or legend text are visible in this scan.

Home/ Registry/ Ford/ Bronco/ 1992-1996/ “Black Iron Horse”/ Photo supermotors.net/registry/media/731204

1980-96 Ford Bronco Body Mount & Radiator Support Exploded Parts Diagram

Exploded view of 1980-96 Bronco frame body mounts showing bolts, bushings and brackets by position

‹ ›

Exploded parts diagram of 1980-96 Bronco body-mount hardware with numbered bolts, bushings and brackets for mount positions 1 through 4.

AI caption May 2009 · Photo 30 of 142

This document is an exploded parts diagram for the body mount and radiator core support mounting hardware on a Ford Bronco, applicable to model years 1980-96 as stated at the top of the drawing. The illustration shows the bare frame in perspective view with callout numbers 1 through 29 identifying the individual fasteners, washers, bushings, insulators, and brackets used at each body mounting point. The hardware is grouped by location: the Radiator Core Support stack uses items 1-8 (a long bolt, washers, insulators/bushings, and a bracket), Position #1 uses items 9-13, Position #2 uses items 14-18 (including a large cylindrical bushing, item 16), Position #3 uses items 19-24, and Position #4 uses items 25-29. A red arrow highlights a mounting point on the upper frame rail. From this diagram a reader can learn how many body mount positions exist along the frame, the order in which the bolts, cushions, washers, and retainers stack together at each position, and which components belong to each mount when disassembling or replacing worn body mount bushings. No part numbers, torque specifications, or textual legend describing each numbered item are included in this scan.

Is this accurate? Sign in to help verify it.

Frequently asked questions

What years of Ford Bronco does this body mount diagram cover?: The diagram is labeled 'Bronco 1980-96', so it covers 1980 through 1996 Ford Broncos.
How many body mount positions are shown on the Bronco frame?: The diagram shows the Radiator Core Support mount plus four numbered body mount positions: Position #1, Position #2, Position #3, and Position #4.
Which callout numbers correspond to each mount position?: Radiator Core Support uses items 1-8, Position #1 uses items 9-13, Position #2 uses items 14-18, Position #3 uses items 19-24, and Position #4 uses items 25-29.
Does this diagram include part numbers or torque specs for the body mounts?: No. It only shows numbered callouts for the hardware stacks at each mount position; no part numbers, torque values, or legend text are visible in this scan.
