1995 Ford Bronco Exhaust Y-Pipe with Catalytic Converter Diagram – Part 48-5594

This document is a cropped exploded-parts style illustration of an exhaust Y-pipe assembly with an integrated catalytic converter, uploaded as a reference for a 1995 Ford Bronco. The line drawing shows a dual-inlet Y-pipe: two flanged inlet connections (each with a two-bolt flange) merging into a single outlet pipe that passes through an oval catalytic converter body before continuing as a straight pipe. Visible text specifies the pipe size as 2-1/4 inches and an overall length dimension of 48 inches measured along the main pipe run. The part is identified by catalog/part number 48-5594. A partially cut-off word at the top appears to read 'Warranty,' suggesting the illustration was clipped from a parts catalog page. No manufacturer name, vehicle applicability (year, make, model, or engine), torque specifications, or installation instructions are visible in the cropped image. A reader can learn the part number, pipe diameter, approximate length, and general configuration (two-into-one Y-pipe with converter) of this exhaust component, which is useful for identifying or ordering a replacement Y-pipe/catalytic converter assembly.
