Enclosed V-Nose Trailer Fabrication Plan View - Doors, Windows & Ramp Layout

This document is a fabrication plan-view (top-down) blueprint of an enclosed V-nose trailer, showing the layout of doors, windows, and structural features as seen from above. The drawing is a line diagram with labeled callouts pointing to features around the trailer body. On one side wall are two 36"x22" tinted windows with horizontal sliders (one also specified with egress capability), plus a 32" RV door with screen and window. The front of the trailer features a 3-foot "V" nose, a 24" standard entry door located on the angled nose section, and a 60" triple tube tongue extending forward for hitching. The rear of the trailer has a full-width rear ramp door. A 2'x2' locking access door is located near the front on one side. Dashed rectangles inside the body indicate wheel wells for a narrowed axle, allowing the wheels to intrude into the interior space. No overall length, width, or height dimensions, year, manufacturer, or part numbers are shown. A reader can learn the placement and specified sizes of all door and window openings for fabricating or ordering this custom enclosed trailer. Despite being filed under a 1996 Ford Bronco gallery, the drawing depicts a trailer, not the vehicle itself.
