Ford Bronco Tailgate Glass & Window Regulator Removal - Haynes Diagram

This is a photographed page from a Haynes repair manual covering the Ford Bronco tailgate glass and window regulator. The page contains a large exploded diagram labeled as showing Bronco tailgate glass and regulator installation details, with a main view of the tailgate assembly plus four detail insets (Views A-D). Callouts identify the tail gate assembly, torsion bar, access panel support, interior access cover panel, regulator assembly, motor, weatherstrip assembly, seal assembly, run assembly, back window, adjusting screw & washer, bumper, bracket, retainer, glass, spacer, rivet, switch assembly, door lock cylinder retainer, and cylinder. The accompanying step-by-step procedure covers regulator removal (with a warning that the counterbalance spring is under tension and the gear sector should be clamped before removing the motor) and glass removal: lowering the tailgate, removing the access panel/water shield/panel support, raising the glass to access the retaining nuts (or drilling 5/8-inch access holes using a Ford dealer template if the glass will not rise), grinding off rivet heads, disconnecting the rear window defogger if equipped, removing corner seals and weatherstrip, sliding the glass out, cleaning metal filings and touch-up painting drilled holes, and cycling the window after reinstallation. Portions of the left and right text columns are cut off at the page edges.
