1986 Ford Bronco Speaker Box Blueprint Sketch - 40 x 17 x 14 Inch Enclosure
Reference · 1980-1986 BroncoAll 26 blueprints
Dimensioned drawing of a speaker enclosure measuring 40 by 14 by 17 inches with three speaker cutouts.
Part of 1980-1986 Ford Bronco Blueprints
This document is a simple hand-drawn sketch (site-classified as a blueprint) uploaded to the gallery of a 1986 Ford Bronco. It depicts a rectangular box drawn in three-quarter perspective with three oval or round cutouts across its front face, two larger ovals and one smaller circle on the right. Three dimensions are labeled: 14 inches tall, 40 inches wide, and 17 inches deep. No part numbers, materials, speaker sizes, wiring information, or vehicle-specific text appear on the drawing. The sketch most plausibly represents a planned enclosure, such as a speaker/subwoofer box or storage console, sized to fit somewhere in the vehicle, though the drawing itself does not state its purpose. A reader can learn only the overall outer dimensions of the box (40" x 17" x 14") and the general layout of the three cutouts on its front face. There is no year, make, or model information visible, so the drawing neither confirms nor contradicts the claimed 1986 Ford Bronco application.
Is this accurate? Sign in to help verify it.
Frequently asked questions
- What are the dimensions of the box shown in this blueprint?
- The box is labeled 40 inches wide, 17 inches deep, and 14 inches tall.
- How many cutouts are on the front of the box?
- Three cutouts are drawn on the front face: two larger ovals and one smaller, more circular cutout on the right side.
- Does the drawing specify what the box is made of or what it is for?
- No. The sketch shows only the box shape, three cutouts, and the three dimension labels, no materials, purpose, or part information is given.
- Are there any part numbers or vehicle-specific details on this document?
- No part numbers, model names, or years appear anywhere on the drawing.
